Arc Flash Studies: What the Standards Actually Require
Most electrical safety marketing sells personal protective equipment and training. The regulation it points at says something different, and stricter.
Under OSHA 29 CFR 1910.333, employers must de-energise live parts an employee may be exposed to before work begins. Live work is the exception. The standard allows it only where the employer can demonstrate that de-energising introduces a greater hazard, or that equipment design makes it infeasible. PPE is what you fall back on. It is not the plan.
The rule inside the rule
One clause in that standard catches organisations repeatedly. Conductors and equipment that someone de-energised but never locked out or tagged out still count as energised.
Switched off is not the same as safe. A breaker someone else can close, a control someone might bump, an automatic transfer scheme that re-energises a bus — the standard resolves all of that by refusing to recognise an unlocked isolation.
Nothing about that requires new technology or a consultant. It requires a padlock and a procedure, which is why inspectors keep writing it up year after year.
Where NFPA 70E came from
The relationship between OSHA and NFPA 70E confuses people, partly because vendors describe 70E as though it were law.
It is not. OSHA regulations carry legal force; NFPA 70E is a consensus standard. History links the two, though. As OSHA notes in a standards interpretation letter, the agency itself asked for NFPA 70E, wanting a practical method employers could follow to meet its electrical requirements.
The practical consequence: an employer following 70E is generally demonstrating compliance with OSHA Subpart S, while an employer ignoring it must show some other route to the same outcome. OSHA sets out its expectations on the hazard directly in its electric-arc flash material and in a 2024 publication for employers.
What an incident energy study actually calculates
An arc flash study is not an inspection. Nobody walks around with a meter and grades the switchgear.
It is a modelling exercise producing a number: the thermal energy, in calories per square centimetre, that an arc at a given point would deliver to a worker standing a defined distance away. That number sets the PPE rating on the label and the approach boundaries around the equipment.
The calculation method comes from IEEE Std 1584, the guide for performing arc-flash hazard calculations. The 2018 revision rebuilt the model on close to 2,000 additional tests beyond the 2002 edition. It also folded in conductor orientation and enclosure dimensions. One result surprised people: the newer model is frequently less conservative than its predecessor, which means some equipment still wearing an old-method label carries a PPE category higher than the physics justifies.
Inputs decide everything. Available fault current, the gap between conductors, enclosure size, working distance, and above all the protective device clearing time. A bowtie company running that study will ask for your protective device settings before anything else.
Why clearing time dominates the result
This is the part worth understanding even if you never open the report.
Incident energy scales with duration. An arc that a relay clears in two cycles releases a fraction of the energy the same arc releases over half a second. Fault current matters, but time matters more.
Which means the cheapest route to a lower arc flash category is often not thicker clothing. It is a coordination study and a relay setting change — sometimes an arc-energy-reduction setting that engineers switch on only during maintenance, so protection trips faster while someone stands in front of the panel.
An organisation that commissions incident energy studies and then ignores the coordination recommendations has bought labels, not safety.
Where EV charging changes the picture
Charging infrastructure has pulled substantial new load into buildings whose distribution boards date from a different era, and that carries a specific consequence for arc flash.
Adding capacity generally raises available fault current. Raising fault current invalidates the incident energy study performed before the upgrade. Labels reflecting the old fault level now understate exposure, and nothing on the panel announces it.
The trigger for restudy is therefore not a calendar interval. Any change to the supply transformer, service capacity, protective device settings or major connected load triggers it. Charging installations hit at least two of those.
None of this is exotic engineering. It is bookkeeping about energy, kept current, with a padlock at the front.
